TPI 717 Flue Gas Analyzer with Smart Sensors

Model: 717 | UPC: 636623007170

The TPI 717 combustion analyzer is a state of the art, easy to use analyzer designed not only to display and calculate the required readings from a flue but also to cover most of the other measurements associated with combustion.

Discontinued!

This product has been discontinued and is no longer available. There is no direct replacement. Don't worry, we have some options to help you find what you need:

Visit our Combustion Analyzers category for similar products.

Or let's do a search and help you find what you need:

TPI 717 Offers

Fast purge and the ability to perform fuel selection during start up enable tests to be performed quickly without requiring extra set-up time after initial startup. TPI analyzers also use the last selected fuel as the default setting. This feature prevents the need to perform fuel selection every time the analyzer is turned on.

Features

Combustion Efficiency Analyzer: Measure O2, CO, and flue temperature. Calculate efficiency, excess air, CO2 & (CO/CO2) Ratio.
CO Analyzer: Measure carbon monoxide in ambient air.
Differential Manometer: +/- 150 mBar (0.01 mBar resolution). Great for tightness/let by or burner pressure testing.
Differential Thermometer: Dual input K-Type thermocouple thermometer measures differential temperatures. Ideal for measuring & recording flow & return temperatures.
Integrated Magnet for hands-free use; Push on fittings for fast and easy use

Applications

Use TPI analyzers to test flue gases in gas and oil fired equipment including high efficiency furnaces and condensing boilers.

TPI 717 Specifications

Operating Temperature Range	-10℃ to +50℃
Battery / Battery Life	AA (3) / > 6 Hours
Fuels	Natural Gas, LPG, Light Oil, Heavy Oil, Bituminous Coal, Anthracite Coal, Coke, Butane, Wood, Wood Pellet, Bagasse
Units of Pressure	mbar, kPa, inH2O
Display	3 Line Backlit LCD w/ annunciators
Data Storage	100 sets of readings
Time & Date	24 Hour Real Time Clock
Dimensions	7.8" X 3.5" X 2.4"
Weight	1.1lbs

Click here for complete specifications on the TPI 717

What's included with the TPI 717

TPI 717 Instrument
Rubber Boot (A765)
Soft Carrying Case (A768)
Flue Sampling Probe (A770)
In-Line Filter assembly installed on Flue probe (A796)
Temperature Probe (GK11M)
Mini Pump Protection Filter Assembly and spare filters (A763)
Exhaust Spigot (removable) (A764)
Instruction Manual

TPI 717 Flue Gas Analyzer with Smart Sensors: Overview

This video will go over the key features and accessories included with this gas analyzer with smart sensors. Also, this instrument is designed not only to display and calculate the required readings from a flue but also to cover most of the other measurements associated with combustion.
