The lead-free, stainless-steel pressure gauge is ideal for hydraulic and pneumatic installations requiring instrument orientation. It has a 0/600 psi/kPa range and a pulsation-resistant, glycerin-filled, stainless-steel case. It comes with a 2.5" (6.4 cm) dial and polycarbonate lens.
The lead-free, stainless-steel pressure gauge is ideal for hydraulic and pneumatic installations requiring instrument orientation. It has a 0/600 psi/kPa range and a pulsation-resistant, glycerin-filled, stainless-steel case. It comes with a 2.5" (6.4 cm) dial and polycarbonate lens.
These lead-free, stainless-steel pressure gauges are ideal for hydraulic and pneumatic installations requiring instrument orientation. Featuring a pulsation-resistant and glycerin-filled, stainless-steel case. Comes with 2.5" (6.4 cm) dial and polycarbonate lens.
These lead-free, stainless-steel pressure gauges are ideal for hydraulic and pneumatic installations requiring instrument orientation. Featuring a pulsation-resistant and glycerin-filled, stainless-steel case. Comes with 2.5" (6.4 cm) dial and polycarbonate lens.
Features
Applications
| Range | 0/600 psi/kPa |
| Range | 0/600 psi/kPa |
| Connection | 0.25" (0.64 cm) back (CB) |
| Connection | 0.25" (0.64 cm) back (CB) |
| Dial | 2.5" (63 mm) white aluminum with black and red markings |
| Dial | 2.5" (63 mm) white aluminum with black and red markings |
| Case | AISI 304 SS |
| Case | AISI 304 SS |
| Lens | Polycarbonate |
| Lens | Polycarbonate |
| Ring | AISI 304 SS, crimp-on |
| Ring | AISI 304 SS, crimp-on |
| Fill Liquid | Glycerin |
| Fill Liquid | Glycerin |
| Working Pressure | Maximum 75% of full-scale value |
| Working Pressure | Maximum 75% of full-scale value |
| Ambient/Process Temperature | -4 to 150°F (-20 to 65°C) |
| Ambient/Process Temperature | -4 to 150°F (-20 to 65°C) |
| Accuracy | ±1.5% of full scale |
| Accuracy | ±1.5% of full scale |
| Range | 0/600 psi/kPa |
| Range | 0/600 psi/kPa |
| Connection | 0.25" (0.64 cm) back (CB) |
| Connection | 0.25" (0.64 cm) back (CB) |
| Dial | 2.5" (63 mm) white aluminum with black and red markings |
| Dial | 2.5" (63 mm) white aluminum with black and red markings |
| Case | AISI 304 SS |
| Case | AISI 304 SS |
| Lens | Polycarbonate |
| Lens | Polycarbonate |
| Ring | AISI 304 SS, crimp-on |
| Ring | AISI 304 SS, crimp-on |
| Fill Liquid | Glycerin |
| Fill Liquid | Glycerin |
| Working Pressure | Maximum 75% of full-scale value |
| Working Pressure | Maximum 75% of full-scale value |
| Ambient/Process Temperature | -4 to 150°F (-20 to 65°C) |
| Ambient/Process Temperature | -4 to 150°F (-20 to 65°C) |
| Accuracy | ±1.5% of full scale |
| Accuracy | ±1.5% of full scale |
