Winters PFP832 Premium Stainless-Steel Liquid Filled Pressure Gauge, 0/5,000 psi/kPa, 0.25" bottom

Model: PFP832 | UPC: 628311242720

Winters PFP832 Premium Stainless-Steel Liquid Filled Pressure Gauge, 0/5,000 psi/kPa, 0.25&quot; bottom-

Image is for reference only, refer to product info for complete details.

Downloads: datasheet

Winters PFP832 Premium Stainless-Steel Liquid Filled Pressure Gauge, 0/5,000 psi/kPa, 0.25" bottom

Model: PFP832 | UPC: 628311242720

The premium stainless-steel, liquid-filled pressure gauge with 2.5" (6.4 cm) dial comes with a 0.25" (0.64 cm) bottom connection and a range of 0/5,000 psi/kPa. It is highly accurate with an accuracy rate of ±1.5% of full-scale value. It features stainless-steel internals and a case that protects it against vibration and pulsation. Dual scale.

Sale Price	$61.15 USD
Regular Price	$135.88 USD
Availability	2 to 3 Weeks
Quantity	Quantity

Winters PFP832 Offers

The premium stainless-steel, liquid-filled pressure gauges with 2.5" (6.4 cm) dial come with a 0.25" (0.64 cm) bottom connection. They are highly accurate with an accuracy rate of ±1.5% of full-scale value. These gauges feature stainless-steel internals and a case that protects against vibration and pulsation. Dual scale.

Features

Liquid-filled, stainless-steel case protects against vibration and pulsation
Liquid-filled, stainless-steel case protects against vibration and pulsation
Highly accurate
Highly accurate
Back, bottom or panel mounted
Back, bottom or panel mounted
Under and overload stops
Under and overload stops
Ventable plug on 2.5" to 4.5" (6.35 to 11.4 cm) stainless-steel and 4.5" (11.4 cm) brass bottom mount and 4" (10.2 cm) stainless-steel back mount gauges
Ventable plug on 2.5" to 4.5" (6.35 to 11.4 cm) stainless-steel and 4.5" (11.4 cm) brass bottom mount and 4" (10.2 cm) stainless-steel back mount gauges
Stainless steel or brass wetted parts
Stainless steel or brass wetted parts
Restrictor screw standard on dual scale (optional on single scale)
Restrictor screw standard on dual scale (optional on single scale)
Dry case available
Dry case available
ASME B40.100 compliant (EN837-1 available)
ASME B40.100 compliant (EN837-1 available)
RoHS compliant (SS internals only)
RoHS compliant (SS internals only)
CRN registered
CRN registered
5-year warranty
5-year warranty

Applications

Outdoor And Severe Ambient And Process Conditions
Outdoor And Severe Ambient And Process Conditions
Use Where Harmful Vibration And Pulsation Are Present
Use Where Harmful Vibration And Pulsation Are Present
Hydraulic Equipment, Pressure Washers, Oil Field Equipment, Pumps, Compressors And Process Systems
Hydraulic Equipment, Pressure Washers, Oil Field Equipment, Pumps, Compressors And Process Systems

Winters PFP832 Specifications

Range	0/5,000 psi/kPa
Range	0/5,000 psi/kPa
Connection	0.25" (0.64 cm) bottom
Connection	0.25" (0.64 cm) bottom
Dial	2.5" (63 mm) white aluminum with black and red markings
Dial	2.5" (63 mm) white aluminum with black and red markings
Case	AISI 304 SS
Case	AISI 304 SS
Lens	Polycarbonate, high pressure BSP(G) and HP: tempered safety glass
Lens	Polycarbonate, high pressure BSP(G) and HP: tempered safety glass
Ring	AISI 304 SS
Ring	AISI 304 SS
Fill Liquid	Glycerin
Fill Liquid	Glycerin
Working Pressure	Maximum 75% of full-scale value
Working Pressure	Maximum 75% of full-scale value
Ambient/Process Temperature	-4 to 150°F (-20 to 65°C)
Ambient/Process Temperature	-4 to 150°F (-20 to 65°C)
Accuracy	±1.5% of full scale
Accuracy	±1.5% of full scale

Click here for complete specifications on the Winters PFP832

What's included with the Winters PFP832

Winters PFP832 Premium Stainless-Steel Liquid Filled Pressure Gauge, 0/5,000 psi/kPa, 0.25" bottom

datasheet for the Winters PFP832 Premium Stainless-Steel Liquid Filled Pressure Gauge, 0/5,000 psi/kPa, 0.25" bottom
