Winters PFP607 Premium Stainless-Steel Liquid Filled Pressure Gauge, 0/300 psi/kPa, brass internals

Model: PFP607 | UPC: 628311241877

Image is for reference only, refer to product info for complete details.

Downloads: datasheet

Winters PFP607 Premium Stainless-Steel Liquid Filled Pressure Gauge, 0/300 psi/kPa, brass internals

Model: PFP607 | UPC: 628311241877

The premium stainless-steel, liquid-filled pressure gauge with 4" (10.2 cm) dial comes with a 0.25" (0.64 cm) bottom connection and a range of 0/300 psi/kPa. It is highly accurate with an accuracy rate of ±1% ANSI/ASME Grade 1A. It features brass internals and a stainless-steel case that protects it against vibration and pulsation. Dual scale.

Sale Price	$81.23 USD
Regular Price	$180.50 USD
Availability	2 to 3 Weeks
Quantity	Quantity

Winters PFP607 Offers

The premium stainless-steel, liquid-filled pressure gauges with 2.5" (6.4 cm) dial come with a 0.25" (0.64 cm) bottom connection. They are highly accurate with an accuracy rate of ±1.5% of full-scale value. These gauges feature stainless-steel internals and a case that protects against vibration and pulsation. Dual scale.

Features

Liquid-filled, stainless-steel case protects against vibration and pulsation
Liquid-filled, stainless-steel case protects against vibration and pulsation
Highly accurate
Highly accurate
Back, bottom or panel mounted
Back, bottom or panel mounted
Under and overload stops
Under and overload stops
Ventable plug on 2.5" to 4.5" (6.35 to 11.4 cm) stainless-steel and 4.5" (11.4 cm) brass bottom mount and 4" (10.2 cm) stainless-steel back mount gauges
Ventable plug on 2.5" to 4.5" (6.35 to 11.4 cm) stainless-steel and 4.5" (11.4 cm) brass bottom mount and 4" (10.2 cm) stainless-steel back mount gauges
Stainless steel or brass wetted parts
Stainless steel or brass wetted parts
Restrictor screw standard on dual scale (optional on single scale)
Restrictor screw standard on dual scale (optional on single scale)
Dry case available
Dry case available
ASME B40.100 compliant (EN837-1 available)
ASME B40.100 compliant (EN837-1 available)
RoHS compliant (SS internals only)
RoHS compliant (SS internals only)
CRN registered
CRN registered
5-year warranty
5-year warranty

Applications

Outdoor And Severe Ambient And Process Conditions
Outdoor And Severe Ambient And Process Conditions
Use Where Harmful Vibration And Pulsation Are Present
Use Where Harmful Vibration And Pulsation Are Present
Hydraulic Equipment, Pressure Washers, Oil Field Equipment, Pumps, Compressors And Process Systems
Hydraulic Equipment, Pressure Washers, Oil Field Equipment, Pumps, Compressors And Process Systems

Winters PFP607 Specifications

Range	0/300 psi/kPa
Range	0/300 psi/kPa
Connection	0.25" (0.64 cm) bottom
Connection	0.25" (0.64 cm) bottom
Movement/Socket/Tube	Brass
Movement/Socket/Tube	Brass
Dial	4" (100 mm) white aluminum with black and red markings
Dial	4" (100 mm) white aluminum with black and red markings
Case	AISI 304 SS
Case	AISI 304 SS
Lens	Polycarbonate
Lens	Polycarbonate
Fill Liquid	Glycerin
Fill Liquid	Glycerin
Working Pressure	Maximum 75% of full-scale value
Working Pressure	Maximum 75% of full-scale value
Ambient Temperature	-4 to 150°F (-20 to 65°C)
Ambient Temperature	-4 to 150°F (-20 to 65°C)
Accuracy	±1% ANSI/ASME Grade 1A
Accuracy	±1% ANSI/ASME Grade 1A

Click here for complete specifications on the Winters PFP607

What's included with the Winters PFP607

Winters PFP607 Premium Stainless-Steel Liquid Filled Pressure Gauge, 0/300 psi/kPa, brass internals

datasheet for the Winters PFP607 Premium Stainless-Steel Liquid Filled Pressure Gauge, 0/300 psi/kPa, brass internals
