Ideal for plumbing, heating, and air conditioning, this economy gauge features a case of steel, a 2.5" (63 mm) dial size, a ¼" bottom connection, and a range of 0 to 3,000 psi/kPa.
Ideal for plumbing, heating, and air conditioning, this economy gauge features a case of steel, a 2.5" (63 mm) dial size, a ¼" bottom connection, and a range of 0 to 3,000 psi/kPa.
Features
Applications
| Dial | 2.5" (63 mm) |
| Case | Steel, painted black |
| Lens | Acrylic |
| Ring | Steel, chrome plated |
| Socket | Brass |
| Connection | ¼" NPT standard |
| Bourdon Tube | Phosphor bronze |
| Movement | Brass |
| Pointer | Aluminum, black |
| Welding | Silver alloy |
| Over-pressure Limit | 25% of full scale value |
| Working Pressure | 25% of full scale value |
| Ambient/Process Temperature | -40 to 150°F (-40 to 65°C) |
| Accuracy | ±3-2-3% ANSI/ASME Grade B |
| Enclosure Rating | IP52 |
| Dial | 2.5" (63 mm) |
| Case | Steel, painted black |
| Lens | Acrylic |
| Ring | Steel, chrome plated |
| Socket | Brass |
| Connection | ¼" NPT standard |
| Bourdon Tube | Phosphor bronze |
| Movement | Brass |
| Pointer | Aluminum, black |
| Welding | Silver alloy |
| Over-pressure Limit | 25% of full scale value |
| Working Pressure | 25% of full scale value |
| Ambient/Process Temperature | -40 to 150°F (-40 to 65°C) |
| Accuracy | ±3-2-3% ANSI/ASME Grade B |
| Enclosure Rating | IP52 |
