WIKA 9837825 XSEL; Pressure Gauge, 0 to 160 PSI

Model: 9837825

Image is for reference only, refer to product info for complete details.

Downloads: datasheet manual

WIKA 9837825 XSEL; Pressure Gauge, 0 to 160 PSI

Model: 9837825

The 233.34 gauges are for applications with high dynamic pressure pulsations or vibration. Suitable for corrosive environments and gaseous or liquid media that will not obstruct the pressure system. Features a range of 0 to 160 psi.

Discontinued!

This product has been discontinued and is no longer available. There is no direct replacement. Don't worry, we have some options to help you find what you need:

Visit our Absolute Pressure Gauges category for similar products.

Or let's do a search and help you find what you need:

WIKA 9837825 Offers

Features

Excellent load-cycle stability and shock resistance
4.5" diameter dial size
Vacuum / Compound ranges to 400 psi (25 bar); Positive pressure ranges from 15 psi (1 bar) to 30,000 psi (2,000 bar)
Accuracy of ±0.5% of span; ±1.0% of span for 20,000 psi (1,600 bar) range and above
Single scales with large figures at beginning and end for quick and easy range identification
Glycerine filled case
Black fiberglass-reinforced thermoplastic (POCAN) case, solid front, blow out back, turret-style case with built in rear flange lugs
Clear acrylic window with Buna-N gasket
1/2" NPT lower mount process connection
Welded stainless steel safety gauge
All 316SS wetted parts
Weather resistant (NEMA 3/IP54) without membrane; weather tight (NEMA 4X / IP66) filled case with membrane installed

What's included with the WIKA 9837825

WIKA 9837825 XSEL; Pressure Gauge, 0 to 160 PSI

datasheet for the WIKA 9837825 XSEL; Pressure Gauge, 0 to 160 PSI manual for the WIKA 9837825 XSEL; Pressure Gauge, 0 to 160 PSI

Description ➕➖

WIKA 9837825 Offers

Features

Excellent load-cycle stability and shock resistance
4.5" diameter dial size
Vacuum / Compound ranges to 400 psi (25 bar); Positive pressure ranges from 15 psi (1 bar) to 30,000 psi (2,000 bar)
Accuracy of ±0.5% of span; ±1.0% of span for 20,000 psi (1,600 bar) range and above
Single scales with large figures at beginning and end for quick and easy range identification
Glycerine filled case
Black fiberglass-reinforced thermoplastic (POCAN) case, solid front, blow out back, turret-style case with built in rear flange lugs
Clear acrylic window with Buna-N gasket
1/2" NPT lower mount process connection
Welded stainless steel safety gauge
All 316SS wetted parts
Weather resistant (NEMA 3/IP54) without membrane; weather tight (NEMA 4X / IP66) filled case with membrane installed

Included ➕➖

What's included with the WIKA 9837825

WIKA 9837825 XSEL; Pressure Gauge, 0 to 160 PSI

Resources ➕➖

datasheet for the WIKA 9837825 XSEL; Pressure Gauge, 0 to 160 PSI manual for the WIKA 9837825 XSEL; Pressure Gauge, 0 to 160 PSI
