This room sensor converts temperature readings into a linear analog signal (Current/Voltage) for the BMS. It features a local LCD display, allowing occupants to verify the space temperature easily.
This room sensor converts temperature readings into a linear analog signal (Current/Voltage) for the BMS. It features a local LCD display, allowing occupants to verify the space temperature easily.
| Color | Matte White |
| Display Type | None |
| Electrical Wiring Size | Screw terminals, 18-24 AWG |
| Enclosure Material | High impact ABS plastic |
| IP Protection | IP20 |
| Input Specifications | Class 2; 20 to 30 Vdc, 24 Vac, 50 to 60 Hz |
| Measurement Type | Temperature |
| Operating Humidity | 0 to 95% RH non-condensing |
| Operating Temperature | 0 to 50°C (32 to 122°F) |
| Output Specifications | Selectable 4 to 20 mA, 0 to 5 V, 0 to 10 V |
| Outputs | Analog |
| Override | No |
| Setpoint | No |
| Standards EMC | EN61000 Series to industrial immunity |
| Temperature Measurement Accuracy | ±1.0°C |
| Temperature Measurement Range | 0 to 50°C (32 to 122°F) |
| Temperature Measurement Resolution | 0.1°C (0.1°F) |
| Temperature Sensor Type | Thermistor, 10K Type 2 |
