Compact gloss meter allows for easy one-handed, 3-angle (20/ 60/ 85°) operation.
Compact gloss meter allows for easy one-handed, 3-angle (20/ 60/ 85°) operation.
This gloss meter is capable of measuring up to 200 gloss units (GU) from 3 different angles. The R7700 is designed to meet international gloss measurement standards (ASTMD523, ASTMD1455, ASTMC584 and ASTMD2457), features a backlit LCD and internal memory capable of storing the last 254 measurements. The R7700 can be used in various applications including; automobile paint inspection, stone & tile manufacturing and paint and ink quality assurance processes.
Features
| Measuring Range | 0.1 to 200 GU |
| Measuring Geometry | 20° / 60° / 85° |
| Accuracy | ±1.0 GU |
| Resolution | 0.1 GU |
| Repeatability | ±0.5 GU |
| Measuring Area | 7x14mm (Ellipse) |
| Display | LCD |
| Backlit Display | Yes |
| Auto Shut-off | Yes (after 30 mins) |
| Low Battery Indicator | Yes |
| Power Supply | Rechargeable Lithium Battery |
| Internal Memory | Yes (up to 254 datapoints) |
| Product Certifications | CE / RoHS |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Storage Temperature | -4 to 140°F (-20 to 60°C) |
| Operating Humidity Range | 0 to 85% |
| Dimensions | 5.5 x 1.8 x 3" (140 x 45 x 75 mm) |
| Weight | 10.76oz (305g) |
