Omega HH502 Handheld Thermocouple Thermometer, 2-channel, Type K and J, -200 to 1370°C

Model: HH502

Omega HH502 Handheld Thermocouple Thermometer, 2-channel, Type K and J, -200 to 1370°C

Model: HH502

Built for portable temperature measurement, this handheld thermocouple thermometer takes two Type K and J thermocouple inputs and measures -200 to 1370°C (-328 to 2498°F). It is accurate to ±(0.05% reading + 0.3°C). Powered by 9 V, it works great for portable process temperature checks.

Built for portable temperature measurement, this handheld thermocouple thermometer takes two Type K and J thermocouple inputs and measures -200 to 1370°C (-328 to 2498°F). It is accurate to ±(0.05% reading + 0.3°C). Powered by 9 V, it works great for portable process temperature checks.

Sale Price $233.37 USD
Regular Price $246.95 USD
Availability 2 to 3 Weeks
Quantity

Traceable Calibration Certificate Icon

Traceable Calibration Certificate for your HH502 Handheld Thermocouple Thermometer

Traceable Calibration Certificate Icon

Traceable Calibration Certificate for your HH502 Handheld Thermocouple Thermometer

OMEGA HH502 Offers

Features

  • Types J, K thermocouples
  • Provides max/min, avg, hold, relative
  • Warning beeper with hi/lo setting, time setting on model HH502
  • Dual display function
  • 0.1° resolution
  • Differential thermocouple input
  • Accuracy: stated accuracy at 23 ±5°C <75% RH
  • NEMA 4X (IP56) dustproof
  • Water/splash resistant

Applications

  • Measuring kiln and furnace temperatures with K-type thermocouples
  • HVAC duct and air temperature verification
  • Differential temperature monitoring across heat exchangers (T1-T2)
  • Field calibration checks of industrial process sensors
  • Recording max/min temperatures during equipment commissioning

OMEGA HH502 Specifications

Input type J or K
Power One 9 V battery (included)
Battery life 200 Hours
Display type LCD
Number of digits 25,000
Input channel 2
Temperature range -328 to 2498°F (-200 to 1370°C)
Resolution 0.1°
Display 3
W/Bead wire Type K thermocouple 2
Basic accuracy 0.05% +0.3°C
Dimensions 7.6 x 3.6 x 2.2" (192 H x 91 W x 53 mm D)
Weight Approx 9 oz (255 g)

What's included with the OMEGA HH502

  • Handheld Digital Thermometer
  • Beaded Wire Thermocouple (1 per Channel)
  • Protective Rubber Boot with Tilt Stand
  • 9 V Alkaline Battery
  • Operator's Manual

OMEGA HH502 Offers

Features

  • Types J, K thermocouples
  • Provides max/min, avg, hold, relative
  • Warning beeper with hi/lo setting, time setting on model HH502
  • Dual display function
  • 0.1° resolution
  • Differential thermocouple input
  • Accuracy: stated accuracy at 23 ±5°C <75% RH
  • NEMA 4X (IP56) dustproof
  • Water/splash resistant

Applications

  • Measuring kiln and furnace temperatures with K-type thermocouples
  • HVAC duct and air temperature verification
  • Differential temperature monitoring across heat exchangers (T1-T2)
  • Field calibration checks of industrial process sensors
  • Recording max/min temperatures during equipment commissioning

OMEGA HH502 Specifications

Input type J or K
Power One 9 V battery (included)
Battery life 200 Hours
Display type LCD
Number of digits 25,000
Input channel 2
Temperature range -328 to 2498°F (-200 to 1370°C)
Resolution 0.1°
Display 3
W/Bead wire Type K thermocouple 2
Basic accuracy 0.05% +0.3°C
Dimensions 7.6 x 3.6 x 2.2" (192 H x 91 W x 53 mm D)
Weight Approx 9 oz (255 g)

What's included with the OMEGA HH502

  • Handheld Digital Thermometer
  • Beaded Wire Thermocouple (1 per Channel)
  • Protective Rubber Boot with Tilt Stand
  • 9 V Alkaline Battery
  • Operator's Manual
