The NAVAC NX1G Digital Manifold Gauge delivers fast, high-precision system diagnostics with Class 0.4 accuracy, a responsive 5" HD touchscreen, and real-time wireless data integration for temperature and vacuum measurements. Built with a rugged aluminum body, shock-absorbing corners, and IP54 protection, it’s engineered to perform reliably in demanding HVAC/R environments.
The NAVAC NX1G Digital Manifold Gauge delivers fast, high-precision system diagnostics with Class 0.4 accuracy, a responsive 5" HD touchscreen, and real-time wireless data integration for temperature and vacuum measurements. Built with a rugged aluminum body, shock-absorbing corners, and IP54 protection, it’s engineered to perform reliably in demanding HVAC/R environments.
Features
Powerful Visual w/ HD Color Interface
Precision, Smart and Wireless
Multiple Operation Modes
Rugged and Reliable
Ease of Use
Portability
| Refrigerant Type | R11, R113, R114, R115, R116, R12, R1224yd(Z), R123, R1233zd(E), R1234yf, R1234ze(E), R1234ze(Z), R124, R134a, R22, R23, R236fa, R245fa, R290, R32, R401A, R401B, R402A, R402B, R403A, R403B, R404A, R405A, R406A, R407A, R407B, R407C, R407D, R408A, R409A, R410A, R412A, R413A, R414A, R415A, R416A, R417A, R418A, R419A, R420A, R421A, R422A, R422B, R422C, R423A, R424A, R427A, R428A, R434A, R435A, R436A, R437A, R438A, R439A, R440A, R441A, R442A, R443A, R444A, R448A, R449A, R450A, R452A, R453A, R454A, R454B, R454C, R455A, R456A, R457A, R458A, R459A, R460A, R600, R600a, R601, R601A |
| Screen Configuration | IPS touch screen, 1024 x 512 pixel |
| Ports | 3 x 1/4" SAE |
| Maximum Manifold Pressure | 1087 psi (7500 kPa) |
| Bluetooth Range | 260' (80 m) line of sight |
| Power Supply | Rechargeable 3000 mAh lithium battery, 8 to 10 hours run time, Type-C charging port |
| Language | English, Spanish, French |
Click on a category to view a selection of compatible accessories with the NAVAC NX1G NEXUS 2 Digital Manifold Gauge, bluetooth, A2L, myNAVAC App.
| Refrigerant Type | R11, R113, R114, R115, R116, R12, R1224yd(Z), R123, R1233zd(E), R1234yf, R1234ze(E), R1234ze(Z), R124, R134a, R22, R23, R236fa, R245fa, R290, R32, R401A, R401B, R402A, R402B, R403A, R403B, R404A, R405A, R406A, R407A, R407B, R407C, R407D, R408A, R409A, R410A, R412A, R413A, R414A, R415A, R416A, R417A, R418A, R419A, R420A, R421A, R422A, R422B, R422C, R423A, R424A, R427A, R428A, R434A, R435A, R436A, R437A, R438A, R439A, R440A, R441A, R442A, R443A, R444A, R448A, R449A, R450A, R452A, R453A, R454A, R454B, R454C, R455A, R456A, R457A, R458A, R459A, R460A, R600, R600a, R601, R601A |
| Screen Configuration | IPS touch screen, 1024 x 512 pixel |
| Ports | 3 x 1/4" SAE |
| Maximum Manifold Pressure | 1087 psi (7500 kPa) |
| Bluetooth Range | 260' (80 m) line of sight |
| Power Supply | Rechargeable 3000 mAh lithium battery, 8 to 10 hours run time, Type-C charging port |
| Language | English, Spanish, French |
Click on a category to view a selection of compatible accessories with the NAVAC NX1G NEXUS 2 Digital Manifold Gauge, bluetooth, A2L, myNAVAC App.
