As a smart manifold gauge, the NX1 wirelessly integrates with the MyNAVAC™ App, enabling remote control and monitoring.
As a smart manifold gauge, the NX1 wirelessly integrates with the MyNAVAC™ App, enabling remote control and monitoring.
With Bluetooth connectivity for temperature probes and a micron gauge, it delivers comprehensive insights for versatile applications. The Aluminum Body with a 1/4 Turn Ball Valve ensures reliability and durability. Four operation modes include Manifold, Leak Test, Evacuation, and Decay Test, catering to diverse HVAC needs. The foldable hidden hook enhances portability, while Class 0.4 accuracy and a clear digital display offer precise readings at a glance. Impact-resistant and covered in durable rubber, the NX1 withstands field challenges for a prolonged, resilient work experience.
Features
| Max Over Pressure | 1015.3 psi (70 bar) |
| Refrigerant Types | A-11, A-113, A-114, A-115, A-116, A-12, A-123, A-1233zd, A-1234yf, R-1234ze, R-124, R-125, R-13, R-134a, R-22, R-23, R-236fa, R-245fa, R-290, R-32, R-401A, R-401B, R-402A, R-402B, R-403B, R-404A, R-406A, R-407A, R-407B, R-407C, R-408A, R-409A, R-410A, R-413A, A-414A, R-414B, R-416A, A-417A, R-417C, R-420A, R-421A, R-421B, R-422A, R-422B, R-422C, R-422D, R-424A, R-427 A, R-428A, R-434A, R-437 A, R-438A, R-448A, R-449A, R-450A, R-452A, R-452B, R-453A, A-454B, A-458A, A-500, A-501, A-502, A-503, A-507A, A-508B, A-513A, R-600, R-600A, R-601, R-601A, R-744* |
| Firmware Update | Can be updated at NAVAC website or with MyNAVAC App |
| Max Pressure | 600 psi (4200 kPa) |
| Pressure Units | bar, Mpa, Kpa, psi, kgf/cm² |
| Vacuum Units | Pa, micron, mBar, mmHg |
| Temperature Units | °F, °C |
| Pressure Scale | -1 to 50 bar, -0.1 to 5 Mpa, -100 to 5000 Kpa, -14.5 to 725 psi, -1.02 to 51 kgf/cm² |
| Pressure Resolution | 0.01 bar, 0.001 Mpa, 1 Kpa, 0.1 psi, 0.01 kgf/cm² |
| Temperature Resolution | 32 to 104°F (0 to 40°C) |
| Battery | 3000 mAh Li-polymer |
| Connection | 7/16" (11.11 mm) UNF |
| Sensor | Digital |
| Dimensions | 7.7 x 2.8 x 9" (195.6 x 71.1 x 228.6 mm) |
| Weight | 27 lbs (12.25 kg) |
