Mark-10 M2-500 Series 2 Economical Digital Force Gauge, 500 x 0.5 lbF

Model: M2-500

Downloads: datasheet manual

Mark-10 M2-500 Series 2 Economical Digital Force Gauge, 500 x 0.5 lbF

Model: M2-500

Ideal for simple tension and compression force testing applications up to 500 lbF (2500 N), this force gauge features peak tension and compression readings reliably via the ±0.5% accuracy and 500 Hz sampling rate. In addition, it offers overload protection to 200% of capacity and a large, backlit graphic display with auto-dimming.

Sale Price	$627.00 USD
Regular Price	$660.00 USD
Availability	2 to 3 Weeks2 to 3 Weeks
Quantity	Quantity

Traceable Calibration Certificate for your M2-500 Series 2 Economical Digital Force Gauge

Yes, I would like to add a Traceable Calibration Certificate (Model CERTIFOR1) for only $240.00 USD

Traceable Calibration Certificate for your M2-500 Series 2 Economical Digital Force Gauge

Yes, I would like to add a Traceable Calibration Certificate (Model CERTIFOR1) for only $240.00 USD

Recommended Accessories

Mark-10 AC1052 Force Gauge Mounting Plate, 0.12 - 500 lbF

AC1052

Mark-10 AC1045-1 Force Gauge Adapter kit, 5/16-18F

AC1045-1

Mark-10 G1035 Hook, large, 5/16-18M

G1035

Mark-10 G1061 Wedge Grip

G1061

Mark-10 12-1049 Hard Carrying Case

12-1049

Mark-10 M2-500 Offers

Ruggedly built for many years of service in laboratory and industrial environments, this force gauge features a backlit graphic LCD that displays the current, peak tension or peak compression reading.

Features

Calculates peak tension and compression values
Three selectable units of measurement
Ultra-compact, ergonomic housing
Configurable default measurement unit and mode
500 Hz sampling rate
Large, backlit graphic display with auto-dimming
Powered by rechargeable battery or AC adapter
Reversible housing for alternate load cell orientation

Applications

Basic tension and compression force testing
Production
Laboratory

Mark-10 M2-500 Specifications

Capacity x Resolution	500 x 0.5 lbF 250 x 0.2 kgF 2500 x 2 N
Accuracy	±0.5% of full scale
Sampling Rate	500 Hz
Safe Overload	200% of full scale (display shows "OVER" at 110% and above)
Environmental Requirements	40 to 100°F (4 to 38°C), maximum 96% humidity, non-condensing
Power	AC adapter: 100 to 240 V AC, 50 to 60 Hz, 0.3 A Battery: Rechargeable 8.4 V NiMH Low battery indicator appears when battery level is low, and gauge powers off automatically when power reaches critical stage
Battery Life	Backlight on: Up to 7 hours of continuous use Backlight off: Up to 24 hours of continuous use
Thread	⁵⁄₁₆-18 UNC
Dimensions	4.76 x 2.53 x 1.5" (120.9 x 64.3 x 38.1 mm)
Weight	0.9 lbs (0.41 kg)

Click here for complete specifications on the Mark-10 M2-500

What's included with the Mark-10 M2-500

Force Gauge
Certificate of Conformance
Battery
AC Adapter
Three-Year Warranty

application note Force measurement: A global necessity more than ever datasheet for the Mark-10 M2-500 Series 2 Economical Digital Force Gauge, 500 x 0.5 lbF manual for the Mark-10 M2-500 Series 2 Economical Digital Force Gauge, 500 x 0.5 lbF

Click on a category to view a selection of compatible accessories with the Mark-10 M2-500 Series 2 Economical Digital Force Gauge, 500 x 0.5 lbF.

Grips

MARK-10 G1102 Wire/Rope Grip, Large G1102

Designed for wire, rope, and yarn pull testing applications. Secures the free end of the sample via a bollard and vise.

Mark-10 G1077 Clevis Grip, 5/16-18F G1077

Designed for ergonomic assessment, spring testing, and other pull testing applications.

Mark-10 G1093 High Capacity Wire Terminal Grip, Eye end G1093

Indexing wheel contains grooves of varying widths to accommodate a wide range of sample shapes and sizes.

Mark-10 G1061 Wedge Grip G1061

Heavy duty self-tightening grips with a capacity range of 50 lbf to 2,000 lbF (250 N to 9 kN). Used for tensile testing of a wide ranges of materials.

Mark-10 G1100 Parallel Jaw/Vice-Action Grip, 2000 lbF, large G1100

Ideal for general tensile and pull testing applications up to 2000 lbF (9 kN), this rugged grip includes an adjustable stop for consistent sample placement between the jaws, as well as an integrated eye end mounting. Requires an eye end adapter to mount to Mark-10 force gauges or force sensors, and test stands.

Mark-10 G1111 Ribbon Wrap Grip for ASTM D6775 G1111

Ideal for conformance to ASTM D6775 and related standards, this wrap grip secures textile webbing, tape, and braided materials typically used in construction, shipping, and other industrial uses. Additionally, this instrument accommodates a wide range of sample widths and forces up to 2,000 lbF (10 kN).

Mark-10 G1094 High Capacity Eccentric Roller Grip, Eye end G1094

This rugged grip features a serrated cam, for effectively securing wires, plastics, textiles, and other materials in pull testing applications.

Mark-10 G1090 High Capacity Clevis Grip, Eye end G1090

This grip features a spring loaded pin with ball plunger that locks into place, for added safety during pull testing.

Mark-10 G1076 Wire Terminal Grip, 0.03-0.25in Grooves, 5/16-18F G1076

For securing wire terminals, cables, connectors, and other samples for pull testing. Indexing wheel contains grooves of varying widths to accommodate a wide range of sample shapes and sizes.

Mark-10 G1085 Dual Roller Grip, Adjustable, 0-1in Opening, 5/16-18F G1085

This cam grip secures the ends of tubing, cables, and odd shaped samples for pull testing applications. Engaging and disengaging samples is quick and easy, with a side slot for sample insertion and serrated steel rollers. The rollers can be repositioned to the desired spacing, accommodating a broad range of sample widths up to 1" (25 mm).

Mark-10 G1061-2 Wedge Grip, 1in Jaw Width, 1/2-20F G1061-2

This heavy duty self-tightening grip with a capacity of 2000 lbF (9.0 kN) is ideal for tensile testing. The jaws ride on rollers instead of sliding along the surface of the housing, as with conventional wedge grips. This unique design prevents jamming and improves gripping characteristics.

Mark-10 G1092 High Capacity Wire / Rope Grip G1092

For high capacity wire and rope pull testing applications. Secures the free end of the sample via a bollard and vise. Integrated eye end.

Power Supplies

Mark-10 AC1031 AC Adapter, 220V Euro AC1031

Compatible with Mark 10 Force and Torque Gauges.

Mark-10 AC1030 AC Adapter, 110V US AC1030

Compatible with Mark 10 Force and Torque Gauges.

Mark-10 AC1032 AC Adapter, 220V UK AC1032

Compatible with Mark 10 Force and Torque Gauges.

Mark-10 AC1035 AC Adapter, 220V Aus AC1035

Compatible with Mark 10 Force and Torque Gauges.

Mark-10 AC1118 Rechargeable Battery, 8.4V NiMH AC1118

The 8.4V NiMH AC1118 battery is designed for use with new Mark-10 gauges. They can also be used with legacy gauges, however, some modifications are required.

Mounting Plates

Mark-10 AC1052 Force Gauge Mounting Plate, 0.12 - 500 lbF AC1052

These universal mounting plate kits are suitable for all Mark-10 force gauges in OEM and custom mounting applications. The plates feature an integrated dowel pin, which mates with the blind hole in the rear of Mark-10 force gauge housings.

Attachments

Mark-10 G1020 Padded Attachment, Rectangular, 5/16-18F G1020

For applications in physical therapy and ergonomics, including muscle strength testing, job task requirements, and more.

Mark-10 G1021 Padded Attachment, Curved, 5/16-18F G1021

For applications in physical therapy and ergonomics, including muscle strength testing, job task requirements, and more.

Mark-10 G1037 Coupling, 5/16-18F/F G1037

For use between force gauge shafts, test stands, grips, and attachments.

Mark-10 G1035 Hook, large, 5/16-18M G1035

For pull testing of various samples.

Mark-10 G1036 Flat Head, 5/16-18F G1036

For compression testing of buttons, membrane switches, etc.

Mark-10 G1034 V-groove, 5/16-18F G1034

For compression testing of round or odd-shaped samples.

Mark-10 G1033 Cone Point, 5/16-18F G1033

For various compression and puncture testing applications.

Mark-10 G1032 Chisel Point, 5/16-18F G1032

For compression testing applications.

Mark-10 G1031 Extension Rod, 5in, 5/16-18M/F G1031

For use between a force gauge and another attachment, such as a hook or compression plate.

Mark-10 G1019 Padded Attachment, Square, 5/16-18F G1019

For applications in physical therapy and ergonomics, including muscle strength testing, job task requirements, and more.

Mark-10 23-1031-3 Attachments Kit for M2-200 - M2-500 Gauges 23-1031-3

Accessory kit for Mark 10 M2-200 and M2-500 Force Gauges. This kit includes a hook, flat, cone, chisel, v-groove, and extension rod.

Mark-10 G1112 Padded Attachment, circular G1112

Designed for testing muscle strength and other job task requirements, the circular padded attachment works with force gauges. It has a capacity of 500 lbF (2,500 N). It has a 3" diameter and a 5/16-18F thread.

Compression Plates

Mark-10 G1009-1 Compression Plate, 3in dia., 5/16-18F G1009-1

For compressing springs, foams, cartons, aerosol cans, and many other products.

Mark-10 G1087-1 Compression Plate, 2.20in dia., Eye end G1087-1

The plates feature integrated eye ends, and require eye end adapters to mount to Mark-10 force gauges, load cells, and test stands.

Mark-10 G1009-3 Compression Plate with vented channels, 3" G1009-3

This 3" aluminum compression plate is ideal for testing springs, foams, and other materials. The plates attach directly to Mark-10 force gauges and test stands.

Mark-10 G1087 Compression Plate, 3.78in dia., Eye end G1087

The plates feature integrated eye ends, and require eye end adapters to mount to Mark-10 force gauges, load cells, and test stands.

Adapter Kits

Mark-10 AC1045-1 Force Gauge Adapter kit, 5/16-18F AC1045-1

Force gauges with 200, 300, and 500 lbF capacities.

Carrying Cases

Mark-10 12-1049 Hard Carrying Case 12-1049

Cushioned hard plastic carrying case provides storage space for the gauge, AC adapter, and attachments.

Fixtures

Mark-10 G1096 High Capacity Bend Fixture, 2000 lbF, Eye end G1096

Designed for 3-point and 4-point bend testing of plastics, metals, ceramics, tubing, and many other materials.

Mark-10 G1097 Upper Anvil for Bend Fixtures, 2,000 lbF, Eye end G1097

Used with bend fixture for a 3 point bend testing.

Mark-10 G1095 Bend Fixture, 500 lbF, Eye end G1095

Designed for 3-point and 4-point bend testing of plastics, metals, ceramics, tubing, and many other materials.
