This refrigerated/heating circulator features an adjustable power pump and a 3.5in (8.89cm) color TFT display. It is also equipped with an analog interface.
This refrigerated/heating circulator features an adjustable power pump and a 3.5in (8.89cm) color TFT display. It is also equipped with an analog interface.
This product exceeds standard shipping dimensions/weight, as such it does not qualify for free shipping and will be shipped directly from the manufacturer. We will contact you with your shipping costs.
The Julabo DYNEO DD-200F Refrigerated/Heating Circulator boasts a voltage of 230 V and is designed for internal and external temperature control applications. It can withstand an ambient temperature range of -4 to 392°F (-20 to 200°C) and can easily transition between internal and external circulation. The circulator also boasts an optimized cooling coil design that helps save space in the bath tank and an adjustable pressure pump with a flow rate of 5.8 GPM (22 LPM).
Features
| Temperature Range | -4 to 392°F (-20 to 200°C) |
| Temperature Control Type | PID |
| Temperature Stability | ±0.01°C |
| Display Type | TFT |
| Display Size | 3.5" (8.89 cm) |
| Heating Capacity (kW) | 1 |
| Cooling Capacity (kW) | 0.02 to 0.2 |
| Cooling Capacity | -4 to 392°F (-20 to 200°C) |
| Pump Flow Rate | 5.8 GPM (22 LPM) |
| Pump Flow Pressure | 8.7 psi |
| Maximum Viscosity | 50 cSt |
| Pump Connectors | M16x1 |
| Fittings Diameter | 0.31"/0.47" (8 mm/12 mm) |
| Filling Volume | 1.06 gal (4 L) |
| Compatible Refrigerant | R134a |
| Carbon Dioxide Equivalent (t) | 0.1 |
| Interfaces | Analog, USB |
| Ambient Temperature | 41 to 104°F (5 to 40°C) |
| Tank Material | Stainless steel |
| Product Length | 15.4" (39.12 cm) |
| Product Width | 9.1" (23.11 cm) |
| Product Height | 25.6" (65.02 cm) |
| Product Weight | 56.7 lbs (25.72 kg) |
| Manufacturer Warranty | 2-year limited/10,000-hour operation |
