Imada DIR-IP200 Digital Torque Tester with Remote Sensor, 20.00 kgf-m

Model: DIR-IP200

Downloads: manual

Imada DIR-IP200 Digital Torque Tester with Remote Sensor, 20.00 kgf-m

Model: DIR-IP200

Digital Torque Tester is ideal for quickly checking click type, dial and digital torque wrenches. Features programmable High/Low setpoints with GO/NO GO LED indicators and an audible beep.

Your Price	$1490.00 USD
Availability	1 Week
Quantity	Quantity

IMADA DIR-IP200 Offers

The DIS-IP Series features several models ranging up to 362 lbf-ft. It has an accuracy of ±0.5% FS, ±1 LSD. Select Peak, Real Time, Continuous or Peak Down measurement modes.

Features

Programmable High/Low setpoints with GO/NO GO LED indicators and audible beep
Peak, Real Time and Peak Down measuring modes (selectable)
Selectable units lbf-in, kgf-cm, N-cm, or lbf-ft, kgf-m, N-m
USB virtual COM port sends peak (1 data) or continuous data (12 or 180 data/second)
Statistics: number of data, Max, Min, Avg
800 data memory for recall or for SPC download
Accuracy: ±0.5% FS ±1 LSD (32 to 100°F)
Both clockwise and counterclockwise operation
Heavy duty metal construction
Runs on internal NiCad batteries (8 hour use)
AC adapter/charger included

Imada DIS-IP200 Specifications

Capacity
lbf-in	20 to 1740
lbf-ft	2.0 to 145.0
N-cm	0.20 to 20.00
N-m	2.0 to 200.0
General Specifications
Accuracy	±0.5% FS, ±1 LSD
Dimensions	4.13 x 3.93 x 1.57"

What's included with the IMADA DIR-IP200

Digital Torque Tester
Display
Sensor
Sensor Cable
AC Adapter and Charger
Carrying Case

DIS-IP Digital Torque Tester - Peak Down Torque Testing

manual for the Imada DIR-IP200 Digital Torque Tester with Remote Sensor, 20.00 kgf-m
