Hioki CM4376 AC/DC Clamp Meter, 1000 A

Model: CM4376

Downloads: datasheet manual

Hioki CM4376 AC/DC Clamp Meter, 1000 A

Model: CM4376

Uniquely designed, this clamp meter features a slim jaw that lets you get into the narrow gaps between cables in crowded electrical distribution boxes without damaging the cables or the clamp meter. Features an IP54 dustproof and waterproof enclosure to enable professionals to work quickly in challenging situations.

Discontinued!

This product has been discontinued and is no longer available.
This is the direct replacement:

HIOKI CM4375-90 AC/DC Clamp Meter with wireless adapter, 1000 A

Model: CM4375-90

Make testing in crowded areas easier with this clamp meter's innovative slim jaw design, which measures up to 1000 A AC/DC while also measuring inrush current in RMS and crest values. In addition, the Bluetooth wireless adapter allows data management via the Gennect Cross app.

Learn More

Recommended Accessories

Hioki L4937 Magnetic Adapter Set, 1,000V

L4937

Hioki L4934 Alligator Clip Set, Small

L4934

Hioki L4933 Contact Pin Set, 70VDC/33VAC, Black/Red

L4933

Hioki L4932 Digital Multimeter Test Pin Set, Cat IV 600V/Cat III 1,000V

L4932

Hioki L4930 Connection Cable Set, 3.94ft

L4930

Hioki DT4910 K-Type Thermocouple, -40 to 500°F

DT4910

Hioki CM4376 Offers

The high-voltage DC measurement capability of up to 1700 V is ideal for the clamp maintenance inspections of electrical and solar power equipment. Finally, built-in Bluetooth wireless technology lets you send measured values to a smartphone or tablet, display waveforms in real time, and create reports right on site.

Features

Easily get into tight spaces between cables thanks to thin sensor structure
Measure up to 1000 A
Automatic AC/DC function helps boost work efficiency
Measure DC voltages of up to 1700 V
Simultaneously measure inrush current in RMS and crest values
Expanded -13 to 149°F (-25 to 65°C) operating temperature range
Send measured values to a smartphone or tablet using Bluetooth® wireless technology

Hioki CM4376 Specifications

DC Current Range	1000 A, (Max. display 999.9 A) Basic accuracy: ±1.3% rdg. ±0.3 A (at 30.1 A to 999.9 A)
AC Current Range	1000 A (Max. display 999.9 A, 10 Hz to 1 kHz, True RMS) Basic accuracy 45 to 66 Hz: ±1.3% rdg. ±0.3 A (at 30.1 A to 900.0 A)
Crest Factor	1.5
DC + AC Current Range	1000 A (DC, 10 Hz to 1 kHz, True RMS) Basic accuracy DC, 45 to 66 Hz: ±1.3% rdg. ±1.3 A (at 30.1 A to 900.0 A)
DC Power Range	0.0 VA to 1700 kVA (Automatically switched based on voltage range) Basic accuracy: ±2.0% rdg. ±20 dgt.
DC Voltage Range	600.0 mV to 1500 V 5 ranges Basic accuracy: ±0.5% rdg. ±0.5 mV (at 600 mV)
AC Voltage Range	6.000 to 1000 V 4 ranges (15 Hz to 1 kHz, True RMS) Basic accuracy: ±0.9% rdg. 0.003 V (at 6 V)
DC + AC Voltage Range	6.000 to 1000 V 4 ranges Basic accuracy: DC, 45 to 66 Hz: ±1.0% rdg. ±0.023 V (at 6 V)
Resistance Range	600.0 Ω to 600.0 kΩ 4 ranges Basic accuracy: ±0.7% rdg. ±5 dgt.
Electrostatic Capacity Range	1.000 to 1000 μF 4 ranges Basic accuracy: ±1.9% rdg. ±5 dgt
Frequency Range	9.999 to 999.9 Hz Basic accuracy: ±0.1% rdg. ±1 dgt.
Other Functions	Automatic AC/ DC detection, DC current and DC voltage polarity detection function, MAX/ MIN/ AVG/ PEAK MAX/ PEAK MIN value display, Low-pass filter function, Display value hold, Auto hold, Backlight, Auto power save, Buzzer sound, Zero-adjustment
Interface	Bluetooth® 4.0LE (Bluetooth®) Supported devices: iOS 8 or later, Android™ 4.3 or later smartphone/tablet GENNECT Cross (free downloadable app): display measured values and waveforms, Simple logging function, Waveform monitor function, Hold save function
Power Supply	2 x LR03 Alkaline battery Continuous use: 20 hr (Backlight OFF, Bluetooth® ON)
Core Jaw Diameter	φ1.34" (34 mm)
Smallest Dimension of Jaw Cross-Section	0.37" (9.5 mm)
Dimensions	2.56 x 9.53 x 1.38" (65 x 242 x 35 mm)
Weight	11.6 oz (330 g)

Click here for complete specifications on the Hioki CM4376

What's included with the Hioki CM4376

Clamp Meter
Test LeadD L9207-10
Carrying Case C0203
2 x LR03 Alkaline Battery
Instruction Manual
Precautions Concerning Use of Equipment that Emits Radio Waves

datasheet for the Hioki CM4376 AC/DC Clamp Meter, 1000 A manual for the Hioki CM4376 AC/DC Clamp Meter, 1000 A
