Extech PRC20 Microprocessor Calibrator/Thermometer

Downloads: datasheet manual

Measures eight thermocouple type devices (J, K, T, E, C, R, S and N) and provides precision output displayed as Centigrade/Fahrenheit or mV.

Yes, I would like to add a Traceable Calibration Certificate (Model CERTICA2) for only $205.00 USD

Yes, I would like to add a Traceable Calibration Certificate (Model CERTICA2) for only $205.00 USD

Features

Source and measure 8 thermocouple type devices (J, K, T, E, C, R, S and N)
CJC - Cold Junction Compensation function
Up to five user adjustable calibration presets
Palm-sized double molded housing and large dot-matrix digital backlit LCD with thermocouple type indication
High accuracy calibration function simulates precision thermocouple outputs for use in calibrating thermometers, transmitters, controllers or recorders
Displays output in terms of millivolts or temperature based on thermocouple tables
Mini thermocouple connector
Large battery bank for extended work cycle
External power adapter for continuous work cycle

Applications

Type J Range	-58 to 1832°F
Type K Range	-58 to 2498°F
Type T Range	-184 to 752°F
Type E Range	-58 to 1382°F
Type C Range	32 to 3182°F
Type R/S Range	32 to 3182°F
Type N Range	58 to 2372°F
Voltage	-10.00mV to +60.00mV
Resolution	0.1° (up to 999.9) or 1° (over 999.9°) for J, K, T, E ; 1° for R, N; 0.5° for C, S
Input Impedance	10 MΩ

datasheet for the Extech PRC20 Microprocessor Calibrator/Thermometer manual for the Extech PRC20 Microprocessor Calibrator/Thermometer
