The refrigerant gas leak detector detects all HCFC and HFC refrigerants, 5% hydrogen and 95% nitrogen mixtures with heated diode sensor, high, low, and normal sensitivity options, manual and automatic auto-zero functions.
The refrigerant gas leak detector detects all HCFC and HFC refrigerants, 5% hydrogen and 95% nitrogen mixtures with heated diode sensor, high, low, and normal sensitivity options, manual and automatic auto-zero functions.
Discontinued!
This product has been discontinued and is no longer available. There is no direct replacement. Don't worry, we have some options to help you find what you need:
Visit our Portable Refrigerant Leak Detectors category for similar products.
Or let's do a search and help you find what you need:
Features
| Measuring Element | Semi-conductor sensor |
| Detected Gases | HFC: R134a, R404a, R407c, R410a, R32, R422a/b/c/d, R425a, R507a, R125 HCFC: R22 CFC: R12, R502 Others: H2, R290, R600a, HFO-1234yf, HFO-1234ze |
| Display | 13 LEDs: 8 graphics, 3 sensitivity, 2 battery level and manual auto zero |
| Indication | LED: Gradually lights up when the gas concentration increases Audible: Beep frequency increases when the gas concentration increases |
| Probe | Flexible 11.5" (300 mm) |
| Operating Conditions | 32 to 122°F (0 to 50°C) in non-condensing conditions 0 to 6550' (0 to 2000 m) |
| Housing | Anti-Choc ABS, IP54 |
| Storage Temperature | 4 to 176°F (-20 to 80°C) |
| European Directives | 2014/30/EU EMC ; 2014/35/EU low voltage 2011/65/EU RoHS II ; 2012/19/EU WEEE |
| Power Supply | 4 AAA batteries LR03 1.5 V |
| Keypad | 3 keys |
| Autonomy | >12 hrs |
| Ambiance | Neutral gas |
| Auto Shut-Off | 15 min |
| Weight | 10.5 oz (295 g) |
| Measuring Element | Semi-conductor sensor |
| Detected Gases | HFC: R134a, R404a, R407c, R410a, R32, R422a/b/c/d, R425a, R507a, R125 HCFC: R22 CFC: R12, R502 Others: H2, R290, R600a, HFO-1234yf, HFO-1234ze |
| Display | 13 LEDs: 8 graphics, 3 sensitivity, 2 battery level and manual auto zero |
| Indication | LED: Gradually lights up when the gas concentration increases Audible: Beep frequency increases when the gas concentration increases |
| Probe | Flexible 11.5" (300 mm) |
| Operating Conditions | 32 to 122°F (0 to 50°C) in non-condensing conditions 0 to 6550' (0 to 2000 m) |
| Housing | Anti-Choc ABS, IP54 |
| Storage Temperature | 4 to 176°F (-20 to 80°C) |
| European Directives | 2014/30/EU EMC ; 2014/35/EU low voltage 2011/65/EU RoHS II ; 2012/19/EU WEEE |
| Power Supply | 4 AAA batteries LR03 1.5 V |
| Keypad | 3 keys |
| Autonomy | >12 hrs |
| Ambiance | Neutral gas |
| Auto Shut-Off | 15 min |
| Weight | 10.5 oz (295 g) |
