Perfect for applications where corrosion resistance is necessary, this gauge has a range of 0 to 30 psi and is an economical choice where ambient corrosion and vibration are a concern. Features stainless steel case and ring for excellent protection from harsh processes, and is suitable for fluids that are compatible with brass and bronze.
Perfect for applications where corrosion resistance is necessary, this gauge has a range of 0 to 30 psi and is an economical choice where ambient corrosion and vibration are a concern. Features stainless steel case and ring for excellent protection from harsh processes, and is suitable for fluids that are compatible with brass and bronze.
Features
Applications
| Service | Compatible liquids and gases |
| Wetted Materials | Brass connector, bronze tube |
| Housing | 304 SS |
| Lens | Polycarbonate |
| Accuracy | ±2.5% FS |
| Pressure Limit | FS range |
| Temperature Limits | -4 to 140°F (-20 to 60°C) |
| Size | 1.5" (40 mm) |
| Process Connections | ⅛" male NPT |
| Weight | 2.2 oz (63 g) |
Click on a category to view a selection of compatible accessories with the Dwyer SG1-B10321N Industrial Pressure Gauge, 0 to 30 psi, bottom connection.
