"Our job is helping you do your job"
Works for industrial applications requiring damping, this liquid fillable gauge is ideal for liquids and gases that do not strike the brass measuring system with a pressure range of 0 to 600 psi and a dial size of 4".
Works for industrial applications requiring damping, this liquid fillable gauge is ideal for liquids and gases that do not strike the brass measuring system with a pressure range of 0 to 600 psi and a dial size of 4".
| Pressure Range | 0 to 600 psi |
| Accuracy | ±1% of span |
| Dial Size | 4" (100 mm) |
| Bezel | 304 stainless steel crimped ring |
| Window | Polycarbonate |
| Dial | Dished aluminum, white background, black figures and graduations |
| Pointer | Aluminum, black finish |
| Bourdon Tube | Phosphor bronze |
| Movement | Brass, with underload/overload stops |
| Connection | Brass in one piece, lower mount, ½" NPT male, G ½" BSP |
| Operating Temperature | 140°F (60°C) |
| Case | 304 stainless steel |
