Works for industrial applications requiring damping, this liquid fillable gauge is ideal for liquids and gases that do not strike the brass measuring system and has a pressure range of 0 to 60 psi.
Works for industrial applications requiring damping, this liquid fillable gauge is ideal for liquids and gases that do not strike the brass measuring system and has a pressure range of 0 to 60 psi.
| Pressure Range | 0 to 60 psi |
| Accuracy | ±1.6% of span |
| Dial Size | 2.5" (63 mm) |
| Bezel | 304 stainless steel crimped ring |
| Window | Polycarbonate |
| Dial | Dished aluminum, white background, black figures and graduations |
| Pointer | Aluminum, black finish |
| Bourdon Tube | Phosphor bronze |
| Movement | Brass |
| Connection | Brass, lower mount, ¼" NPT male, G ¼" BSP |
| Operating Temperature | 140°F (60°C) |
| Case | 304 stainless steel |
