Blue-White RB-375PI-LPM1 Paddlewheel Flowmeter, 3 to 30LPM

Model: RB-375PI-LPM1

Image is for reference only, refer to product info for complete details.

Downloads: datasheet manual

Blue-White RB-375PI-LPM1 Paddlewheel Flowmeter, 3 to 30LPM

Model: RB-375PI-LPM1

With union-style connections for easy installation, this paddlewheel flowmeter features a 3 to 30LPM flow rate and has a machined in-line polypropylene body.

Discontinued!

This product has been discontinued and is no longer available. There are no replacement options.

We can help you find what you need:

Blue-White RB-375PI-LPM1 Offers

This paddlewheel flowmeter has easy to read 6 digit LCD and up to 4 decimal positions.

Features

Tamper proof
Battery operated (2 AAA batteries included)
3 model variations: RB = rate only, TB = total only, RT = rate and totalizer
Total reset function can be disabled
Display update time: rate 1.5 sec, total 0.5 sec
Factory calibrated - nothing to program
Custom calibration units available. Contact the factory
Weather resistant ABS enclosure. NEMA 4X
LCD is not recommended for direct sunlight applications

Blue-White RB-375PI-LPM1 Specifications

Max. Working Pressure	300psig (20 bar) @ 70°F (21°C)
Max. Fluid Temperature	200°F (93°C) @ 0psi
Full Scale Accuracy	±2%
Sensor/Paddle/Axle Material	PVDF
O-ring Seals	FKM
Maximum Pressure Drop	8psi (varies per model)

Click here for complete specifications on the Blue-White RB-375PI-LPM1

What's included with the Blue-White RB-375PI-LPM1

Blue-White RB-375PI-LPM1 Paddlewheel Flowmeter, 3 to 30LPM

datasheet for the Blue-White RB-375PI-LPM1 Paddlewheel Flowmeter, 3 to 30LPM manual for the Blue-White RB-375PI-LPM1 Paddlewheel Flowmeter, 3 to 30LPM
