With a liquid flow rate of 0.2 to 2GPM (1 to 7.5LPM), this acrylic flowmeter features 1/2in female NPT connections.
With a liquid flow rate of 0.2 to 2GPM (1 to 7.5LPM), this acrylic flowmeter features 1/2in female NPT connections.
Discontinued!
This product has been discontinued and is no longer available. There is no direct replacement. Don't worry, we have some options to help you find what you need:
Visit our Variable Area Flowmeters category for similar products.
Or let's do a search and help you find what you need:
This acrylic flowmeter features a white or yellow back reflector for easy reading.
Features
| Flow Range (GPM) | 0.2 to 2.0 |
| Flow Range (LPM) | 1.0 to 7.5 |
| Pipe Size (Inch) | 1/2, F/NPT |
| Float Material | Hastelloy |
| Meter Body | Cast Acrylic Rod |
| Adapter Material | Polypropylene |
| O-ring Seals | Viton (Optional EP) |
| Guide Rod | Hastelloy |
| Max. Working Pressure | 150psi (10.3 bar) @ 70°F (21°C) |
| Max. Fluid Temperature | 150°F (65°C) @ 0psig |
| Full Scale Accuracy | ±5% |
| Calibration Fluid | Water, specific gravity 1.0 |
| Scale Length | 4in (10.16cm) |
| Environment | Acceptable for direct sunlight exposure |
| Maximum Pressure Drop (PSI) | 2 |
| Width | 1.26in (32mm) |
| Height | 1.26in (32mm) |
| Length | 8.19in (208mm) |
| Flow Range (GPM) | 0.2 to 2.0 |
| Flow Range (LPM) | 1.0 to 7.5 |
| Pipe Size (Inch) | 1/2, F/NPT |
| Float Material | Hastelloy |
| Meter Body | Cast Acrylic Rod |
| Adapter Material | Polypropylene |
| O-ring Seals | Viton (Optional EP) |
| Guide Rod | Hastelloy |
| Max. Working Pressure | 150psi (10.3 bar) @ 70°F (21°C) |
| Max. Fluid Temperature | 150°F (65°C) @ 0psig |
| Full Scale Accuracy | ±5% |
| Calibration Fluid | Water, specific gravity 1.0 |
| Scale Length | 4in (10.16cm) |
| Environment | Acceptable for direct sunlight exposure |
| Maximum Pressure Drop (PSI) | 2 |
| Width | 1.26in (32mm) |
| Height | 1.26in (32mm) |
| Length | 8.19in (208mm) |
