For TTL and CMOS.
For TTL and CMOS.
Discontinued!
This product has been discontinued and is no longer available. There are no replacement options.
We can help you find what you need:
Features
| Pulse repetition rate | 0.5 pps/400 pps |
| Operation temperature | 0-50ºC, <80% R.H. |
| Storage temperature | -20º to +65ºC, <75% R.H. |
| Pulse width | 10 µs |
| Pulser Mode | 100 mA sink/source |
| Square wave output | 5 mA sink/source |
| Operating supply voltage range | 5-15 V |
| Sync input protection | 1 MΩ |
| Power Supply Protection | 20 V.30 sec. |
| Output Protection | 35 V.30 sec. |
| Sync input protection | 120 V.30 sec. |
| Size (H x W x D) | 0.7" x 0.7" x 8.2" (18 x 18 x 210mm) |
| Weight | 1.4oz (40g) |
