Compact, rugged, and designed to bring laboratory accuracy to outdoor field conditions, this pressure calibrator fits easily into your shirt pocket. Internal sensors give 0.05% of reading accuracy and resist damage from overpressure. Additionally, it has a sensor with a 3000 psi range.
Compact, rugged, and designed to bring laboratory accuracy to outdoor field conditions, this pressure calibrator fits easily into your shirt pocket. Internal sensors give 0.05% of reading accuracy and resist damage from overpressure. Additionally, it has a sensor with a 3000 psi range.
Weigh less than a pound and advanced technology is employed throughout.
Features
Applications
| Pressure Range | 3000 psi |
| Accuracy-Pressure Measurement | 0 to 110% of Range: ±(0.05% of Reading + Floor Term) Floor Term: 0.005% of FS or display resolution, whichever is greater Vacuum: ±(0.25% of Reading + Vacuum Floor Term) Vacuum Floor Term: 0.004 psi for 16 and 36 psi 0.01 psi for 300 ps |
| Accuracy-Milliamperes | Accuracy: ±(0.025% of Reading + 0.001 mA) Range: 0 to 55 mA Resolution: 0.001 mA Connection: 0.1" (4 mm) jacks, 0.75" (19 mm) spacing |
| Screen | 2 lines of up to 6 digits, 0.2" (5 mm) high |
| Digital Interface | Micro-USB |
| Enclosure | Extruded aluminum with sealed membrane keypad |
| Pressure Fitting | &frac;18" female NPT |
| Temperature | Operating: 32 to 122°F (0 to 50°C) Storage: -4 to 158°F (-20 to 70°C) |
| Battery | One alkaline or lithium 9 V battery |
| Weight | 0.94 lb (428 g) |
| Pressure Range | 3000 psi |
| Accuracy-Pressure Measurement | 0 to 110% of Range: ±(0.05% of Reading + Floor Term) Floor Term: 0.005% of FS or display resolution, whichever is greater Vacuum: ±(0.25% of Reading + Vacuum Floor Term) Vacuum Floor Term: 0.004 psi for 16 and 36 psi 0.01 psi for 300 ps |
| Accuracy-Milliamperes | Accuracy: ±(0.025% of Reading + 0.001 mA) Range: 0 to 55 mA Resolution: 0.001 mA Connection: 0.1" (4 mm) jacks, 0.75" (19 mm) spacing |
| Screen | 2 lines of up to 6 digits, 0.2" (5 mm) high |
| Digital Interface | Micro-USB |
| Enclosure | Extruded aluminum with sealed membrane keypad |
| Pressure Fitting | &frac;18" female NPT |
| Temperature | Operating: 32 to 122°F (0 to 50°C) Storage: -4 to 158°F (-20 to 70°C) |
| Battery | One alkaline or lithium 9 V battery |
| Weight | 0.94 lb (428 g) |
