Ideal for absolute pressure applications in natural gas and more, this digital absolute pressure gauge with DataLoggerXP has a 0 to 2000 psia range. Ultra-rugged and intrinsically safe gauge with &plumn;0.02% of full-scale accuracy level. Come with a 14 to 122°F (-10 to 50°C) temperature range.
Ideal for absolute pressure applications in natural gas and more, this digital absolute pressure gauge with DataLoggerXP has a 0 to 2000 psia range. Ultra-rugged and intrinsically safe gauge with &plumn;0.02% of full-scale accuracy level. Come with a 14 to 122°F (-10 to 50°C) temperature range.
Discontinued!
This product has been discontinued and is no longer available.
This is the direct replacement:
Reads accurately at any pressure and temperature.
Features
Applications
| Pressure Range | 2000 psiA |
| Accuracy | ±0.02% of full scale |
| Data Logging | Yes |
| Screen | 5.5 digits |
| Digital Interface | RS232, DB-9F |
| Capacity | 32,000 data points |
| Storage Type | Non-volatile flash memory |
| Enclosure Rating | IP66 and IP67 |
| Housing | Diecast aluminum |
| Sensor | 316 stainless steel |
| Connection | Crystal CPF female |
| Operating Temperature | 14 to 122°F (-10 to 50°C) |
| Power | 3 x AA 1500 hours, typical |
| Pressure Range | 2000 psiA |
| Accuracy | ±0.02% of full scale |
| Data Logging | Yes |
| Screen | 5.5 digits |
| Digital Interface | RS232, DB-9F |
| Capacity | 32,000 data points |
| Storage Type | Non-volatile flash memory |
| Enclosure Rating | IP66 and IP67 |
| Housing | Diecast aluminum |
| Sensor | 316 stainless steel |
| Connection | Crystal CPF female |
| Operating Temperature | 14 to 122°F (-10 to 50°C) |
| Power | 3 x AA 1500 hours, typical |
Configure This Product!
