Accuenergy AcuRev 2010-2EM-RCT-WEB-D Offers

The AcuRev 2000 Series of multi-circuit, multifunction power and energy meters are revenue-grade digital meters engineered for multi-tenant kWh metering and high-density electrical metering.

Features

• Revenue grade standard ANSI C12.20 Class 0.5 and IEC 62053-22 Class 0.5s
• Real-time RMS metering: line and phase voltage, current for each circuit
• Monitors up to 18 circuits/channels/tenants in a single unit
• Energy: Active (kWh), Reactive (kVAR) and Apparent (kVA)
• Power and Power Factor: Active (P), Reactive (Q), Apparent (S), Power Factor
• Demand and peak demand: power and current demand for total and each circuit
• 10-690Vac direct voltage input, fits all voltage rating system with one model
• Multi-tariff Time of Use (TOU) can be used according to different regional billing requirements
• Monitors power quality parameters such as voltage and current THD, individual voltage and current harmonics up to 31st order, voltage crest factor, current K factor, voltage and current unbalance
• Direct voltage measurement of up to 690Vac L-L/400Vac L-N for electrical distribution systems
• Real-time energy metering, power quality and I/O data can be stored in non-volatile onboard memory (8MB)
• Free cloud-based metering data storage (4GB)
• Over/under limit alarms for demand control
• Advanced communications options including serial via Modbus RS485, Modbus via Ethernet, Wi-Fi, BACnet IP, I/O, and infrared communications provide for extensive reliable data exchange
• Built with 8 digital inputs (DI), and 2 digital outputs (DO) to easily integrate other metering data and control in a single unit
• Wide range in power supply thus no control transformer is required
• Split core and flexible Rogowski coil external current transformer options provide the perfect solution for retrofit projects
• Optional direct current input is ideal for new installations
• Display can be either built-in or remote depending on the installation environment

Applications

• Tenant sub-metering
• Energy efficiency studies
• Building/facility management
• Branch circuit monitoring
• Panel metering

Benefits

• Accurate energy reading for billing for multiple tenants
• Verify utility bills to avoid overcharge by using revenue grade and accurate meters
• Identify cost-saving opportunities by viewing the complete picture of energy usage, with detailed consumption historical trending data down to each circuit
• Identify high demand window and locate saving opportunities
